3-150 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
OpOpn ACT BREAKER # OFF CMD (3-phase trip),
BREAKER # TRIP A, BREAKER # TRIP B and
BREAKER # TRIP C operands
R
general BOOLEAN ST BREAKER # OFF CMD R
phsA BOOLEAN ST BREAKER # TRIP A R
phsB BOOLEAN ST BREAKER # TRIP B R
phsC BOOLEAN ST BREAKER # TRIP C R
OpCls ACT BREAKER # ON CMD (close) operand R
general BOOLEAN ST BREAKER # ON CMD R
BadSt1 SPS BREAKER # BAD STATUS operand R
stVal BOOLEAN ST BREAKER # BAD STATUS R
ClsSt1 SPS BREAKER # CLOSED operand R
stVal BOOLEAN ST BREAKER # CLOSED R
OpnSt1 SPS BREAKER # OPEN operand R
stVal BOOLEAN ST BREAKER # OPEN R
Dsc SPS BREAKER # DISCREP operand, which is
breaker pole discrepancy status
R
stVal BOOLEAN ST BREAKER # DISCREP R
Alm SPS BREAKER # TROUBLE operand, which is
breaker pole discrepancy, bad-status, or
BREAKER # EXT ALARM
R
stVal BOOLEAN ST BREAKER # TROUBLE R
MnlOpn SPS BREAKER # MNL OPEN operand R
stVal BOOLEAN ST BREAKER # MNL OPEN R
MnlCls SPS BREAKER # MNL CLS operand R
stVal BOOLEAN ST BREAKER # MNL CLS R
AnyPoleOp
n
SPS BREAKER # ANY P OPEN operand R
stVal BOOLEAN ST BREAKER # ANY P OPEN R
OnePoleOp
n
SPS BREAKER # ONE P OPEN operand R
stVal BOOLEAN ST BREAKER # ONE P OPEN R
OutOfSrv SPS BREAKER # OOS operand R
stVal BOOLEAN ST BREAKER # OOS R
TagOn SPS BREAKER # TAG ON operand R
stVal BOOLEAN ST BREAKER # TAG ON R
TagOff SPS BREAKER # TAG OFF operand R
stVal BOOLEAN ST BREAKER # TAG OFF R
SbstCls SPS BREAKER # SUBD CLSD operand R
stVal BOOLEAN ST BREAKER # SUBD CLSD R
SbstOpn SPS BREAKER # SUBD OPEN operand R
stVal BOOLEAN ST BREAKER # SUBD OPEN R
BypsOn SPS BREAKER # BYPASS ON operand R
stVal BOOLEAN ST BREAKER # BYPASS ON R
BypsOff SPS BREAKER # BYPASS OFF operand R
stVal BOOLEAN ST BREAKER # BYPASS OFF R
RecBlk SPS BREAKER # BLK RCLS operand R
stVal BOOLEAN ST BREAKER # BLK RCLS R
RecEna SPS BREAKER # ENA RCLS operand R
stVal BOOLEAN ST BREAKER # ENA RCLS R
Pos DPC Breaker position control and status R/Ctrl
stVal CODED ENUM ST R
stSeld BOOLEAN ST The controllable data status is “selected” R
LNName: Bkr0XCBR# LDevice inst: System UR element: Breaker Control element #
data obj. data attribute Type FC UR Name Description R/W/C
