3-190 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.6.3 Annunciator (Anctr)
This element is instantiated in the following products: B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90,
M60, N60, T35, T60.
Table 3-206: Annunciator data objects
stVal BOOLEAN ST 8BIT COMP # DPO R
IndΘ SPS 8BIT COMP # BIT Θ operand value R
stVal BOOLEAN ST 8BIT COMP # BIT Θ R
AnOutput1 MV 8BIT COMP # A value R
instMag AnalogueValue MX R
instMag.f FLOAT32 8BIT COMP # A R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
db INT32U CF Cmp8BtGAPC#.AnIn1.db R/W/C
zeroDb INT32U CF 0 R
AnOutput2 MV 8BIT COMP # B value R
instMag AnalogueValue MX R
instMag.f FLOAT32 8BIT COMP # B R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
db INT32U CF Cmp8BtGAPC#.AnIn2.db R/W/C
zeroDb INT32U CF 0 R
AnOutput3 MV 8BIT COMP # Out value R
instMag AnalogueValue MX R
instMag.f FLOAT32 8BIT COMP # Out R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
db INT32U CF Cmp8BtGAPC#.AnIn3.db R/W/C
zeroDb INT32U CF 0 R
InRef1Θ ORG 8BIT COMP # ARG AΘ setting. R
setSrcRef ObjectReference SP 8BIT 8BIT COMP # ARG AΘ
setting
reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef2Θ ORG 8BIT COMP # ARG BΘ setting. R
setSrcRef ObjectReference SP 8BIT 8BIT COMP # ARG BΘ
setting
reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef01 ORG 8BIT COMP # ADD/SUB setting. R
setSrcRef ObjectReference SP 8BIT COMP # ADD/SUB setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
BlkRef01 ORG 8BIT COMP # BLOCK setting R
setSrcRef ObjectReference SP 8BIT COMP # BLOCK reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: AnctrCALH1 LDevice inst: Gen UR element: Annunciator
data obj. data attribute Type FC UR Name Description R/W/C
Mod INC This logical node’s mode R/Ctrl
stVal ENUMERATED ST 1 (on) R
ctlModel CtlModels CF 0 (status only) R
Health INS This logical node’s health R
stVal ENUMERATED ST LPHD1.PhyHealth.stVal R
LNName: Cmp8BtGAPC# LDevice inst: Gen UR element: 8-Bit Comparator #
data obj. data attribute Type FC UR Name Description R/W/C
