CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-205
3
Agnd CMV Ground current (fourth input in a current AC bank).
SRC 1 Ground Current phasor, in primary amperes.
ACsrcMMXN
AgndRMS MV Ground current RMS (fourth input in a current AC bank).
SRC 1 Ground Current RMS, in primary amperes.
ACsrcMMXN
AlgCap SPC Command for the Hi-Z Oscillography Force Algorithm Capture HiZPHIZ
AlmInd SPS An LED.
The LED ALARM operand.
LEDsIHMI
AmpInd SPS An LED.
The LED CURRENT operand.
LEDsIHMI
AnFailBeh ENG Setting to select the behavior of the RxGOOSE Analog when the sending device is
offline: 0 = Default Value, 1 = Last Known
GGIO3
AnFailVal ASG The value of the RxGOOSE Analog when the sending device is offline and the
FailBeh is set to "Default Value"
GGIO3
AnOutput1 MV Analog output Cmp8BtGAPC
AnyPBOn SPS Indicates ANY PB ON operand state. When any of the user pushbuttons is
asserted, status is "true"; when none of the user pushbuttons are asserted, status
is "false."
UsrPbIHMI
AnyErr SPS Any of the self-test errors generated. The ANY SELF TESTS operand. LPHD
AnyGpsFail SPS The GPS signal failed or is not configured properly at any terminal.
The 87L DIFF GPS FAIL operand, which becomes On when the GPS signal failed or
is not configured properly at any terminal.
LinDfPDIF
AnyPoleOpn SPS At least one pole is open. The BREAKER 1 ANY P OPEN operand. Bkr0XCBR
AnyShotCnt SPS The first breaker close signal has been issued.
The AR SHOT CNT greater than zero operand.
Rec13pRREC
APPID ING Expected value of APPID field in messages subscribed to by RxGOOSE#
The RxGOOSE1 ETYPE APPID setting.
LGOS
ArBlk1 SPS Autoreclose Breaker number indicated by the data instance number is
temporarily disabled.
The AR BKR1 BLK operand and the AR1 BLK FROM MAN CLS operand.
Rec13pRREC, Rec3pRREC
ArcConfid1 INS Represents the Arc Confidence in percentage for Phase A, B, C, or N HiZPHIZ
ArcSuspect ACT Indicates suspected element has operated HiZPHIZ
AresRMS MV Residual Current RMS.
SRC 1 Neutral Current RMS, in primary amperes.
ACsrcMMXU
ArLO SPS Autoreclose is locked out. The AR LO operand. Rec13pRREC, Rec3pRREC
Armed SPS Accidental energization. Occurs when the generator is offline with no fault
involved. The ACCDNT ENRG ARMED operand.
AcdEnrPIOC
ArMod1 SPS Autoreclosec mode equals to the number indicated by the data instance number,
in this case 1 and 3 pole mode. The AR MODE = 1 operand.
Rec13pRREC
ArRip SPS Autoreclose is in progress. The AR RIP operand. Rec13pRREC, Rec3pRREC
ASupn1 SPS Indicates the state of current supervision.
The PHS DIST Z1 SUPN AB/BC/CA operand in Phase-To-Phase.
PhsDisPDIS
Asymmetry SPS Communications channel asymmetry detected.
The 87L DIFF CH ASYM DET operand, which becomes On when the differential
element's has detected substantial communications channel asymmetry.
LinDfPDIF
AutoMod SPS Capacitor control in auto mode. The CAP 1 IN AUTO operand. CapCtlGAPC
BadSt1 SPS Bad-status detected. The BREAKER/SWITCH BAD STATUS operand. BkrΘXCBR, Bkr0XCBR,
Disc0XSWI, DiscΘXSWI,
GGIO3
BatFail SPS The battery is not functioning. The BATTERY FAIL operand. LPHD
BDifAClc CMV B90 differential current B_DifPDIF
BiasMotLod MV Indicates thermal model biased motor load.
THERMAL MODEL BIASED MOTOR LOAD in x FLA.
MotThmPTTR
BknRotClr SPC Command to Clear BROKEN ROTOR BAR DATA. TRUE= CLEAR BROKEN ROTOR BAR
DATA
BknRotSVBR
Data object
name
CDC Semantics Used in logical nodes…
