CHAPTER 3: IEC 61850 COMMUNICATION SCL IMPLEMENTATION CONFORMANCE STATEMENT (SICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-221
3
Table 3-226: SCL conformance statement
UR
firmware
UR Setup
software
Value/comments
ICD Export Yes Yes
I11 Fix ICD file (no adaptable export needed) Yes Yes
I12 Export of ICD file or IID file according to IED
preconfiguration performed by tool
I13 State the data model name space (61850-7-3
subclause 7.2) within ICD file (LLN0.NamPlt.ldNs value)
Yes Yes
I14 State the data model version (61850-7-3 subclause
7.8.3) and any predefined / fixed configuration values
within ICD file (9.5.4.4)
Yes Yes
I15 Version 2003 export
I16 Version 2007 export Yes Yes
I17 Predefined data sets
I18 Predefined control blocks Yes Yes
I19 Substation bay template with IED part
I110 Communication section with default address Yes Yes
I111 Export correct valKind value (Table 46)
I112 Exports internal addresses as InRef or Input section
(subclause 9.3.13)
Yes Yes
I113 Exports internal addresses in Input section with
expected serviceType (subclause 9.3.13)
I114 Exports in UTF-8 coding Yes Yes
SCD import If renamed
CID
Yes
I21 Identify IED to be configured in SCD file by IED name Yes
IP address
is used to
locate the
IED name
Yes
I22 Configure LD name (at least via ldInst, dependent on
the IED capabilities) and IED addresses from SCD
Yes Yes
I23 Determine communication side addresses of IED inputs
from SCD
Yes Yes
I24 Determine and use clock communication addresses
from SCD
I25 Configure values of (existing) control block from SCD
(9.3)
Yes Yes
I26 Prepare (new) control block instances according to SCD
file
I26 Prepare / configure data sets according to SCD file Yes Yes
I28 Modify predefined data sets according to SCD
I29 Interpret client references in the control blocks of other
IEDs to find the control block instances allocated to this
IED, and data sent to this IED.
Yes Yes
I210 Set IED configuration values and parameter values as
defined in SCD file
Yes Yes Where configurable
I211 Support changed (reduced capability) valKind (e.g. from
Set to RO or to Conf) (able 46)
I212 Support ldName on other IEDs (9.3.4) Yes Yes
I213 Interpret input signal references to source control
blocks (9.3.13)
Yes Yes
I214 Imports UTF-8 coding of XML Yes Yes
IID export after IED engineering Yes Yes
