2-26 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 13BA ...Repeated for Direct Analog Input and
Output 12
" 13C8 ...Repeated for Direct Analog Input and
Output 13
" 13D6 ...Repeated for Direct Analog Input and
Output 14
" 13E4 ...Repeated for Direct Analog Input and
Output 15
" 13F2 ...Repeated for Direct Analog Input and
Output 16
" 1400 ...Repeated for Direct Analog Input and
Output 17
" 140E ...Repeated for Direct Analog Input and
Output 18
" 141C ...Repeated for Direct Analog Input and
Output 19
" 142A ...Repeated for Direct Analog Input and
Output 20
" 1438 ...Repeated for Direct Analog Input and
Output 21
" 1446 ...Repeated for Direct Analog Input and
Output 22
" 1454 ...Repeated for Direct Analog Input and
Output 23
" 1462 ...Repeated for Direct Analog Input and
Output 24
" 1470 ...Repeated for Direct Analog Input and
Output 25
" 147E ...Repeated for Direct Analog Input and
Output 26
" 148C ...Repeated for Direct Analog Input and
Output 27
" 149A ...Repeated for Direct Analog Input and
Output 28
" 14A8 ...Repeated for Direct Analog Input and
Output 29
" 14B6 ...Repeated for Direct Analog Input and
Output 30
" 14C4 ...Repeated for Direct Analog Input and
Output 31
" 14D2 ...Repeated for Direct Analog Input and
Output 32
Element Targets (Read Only)
All 14E0 Target Sequence 0 to 65535 --- 1 F001 0
" 14E1 Number of Targets 0 to 65535 --- 1 F001 0
Element Targets (Read/Write)
All 14E2 Target to Read 0 to 65535 --- 1 F001 0
" 14F7 Target to Read for GFP 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
All 14E3 Target Message --- --- --- F200 “.”
Contact Input/Output States (Read Only)
All 1500 Contact Input States (8 items) 0 to 65535 --- 1 F500 0
" 1508 Virtual Input States (8 items) 0 to 65535 --- 1 F500 0
" 1510 Contact Output States (5 items) 0 to 65535 --- 1 F500 0
Products Address Register name Range Units Step Format Default
