CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP
D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE 11
014F IEC Protocol Function 0 to 1 --- 1 F126 0 (No)
0150 IEC 61850 Available 0 to 1 --- 1 F126 0 (No)
Settings Notification (Read/Write)
0150 Settings Notification Function 0 to 3 --- 1 F010 3 (N_IDLE)
Settings Notification Actual Values (Read Only)
0151 Settings Notification in Progress 0 to 3 --- 1 F010 0 (N_Clear)
0152 Settings Notification Status 0 to 2 --- 1 F134 0 (N/A)
0153 Settings Notification Load Diagram 0 to 1 --- 1 F102 0 (Disabled)
Settings Notification Commands (Read/Write Command)
0154 Settings Notification Diagram Acknowledge 0 to 2 1 F134 0 (N/A)
Virtual Input Commands (Read/Write Commands) (64 Modules)
0400 Virtual Input 1 Command 0 to 1 --- 1 F108 0 (Off)
0401 Virtual Input 2 Command 0 to 1 --- 1 F108 0 (Off)
0402 Virtual Input 3 Commands 0 to 1 --- 1 F108 0 (Off)
0403 Virtual Input 4 Commands 0 to 1 --- 1 F108 0 (Off)
0404 Virtual Input 5 Commands 0 to 1 --- 1 F108 0 (Off)
0405 Virtual Input 6 Commands 0 to 1 --- 1 F108 0 (Off)
0406 Virtual Input 7 Commands 0 to 1 --- 1 F108 0 (Off)
0407 Virtual Input 8 Commands 0 to 1 --- 1 F108 0 (Off)
0408 Virtual Input 9 Commands 0 to 1 --- 1 F108 0 (Off)
0409 Virtual Input 10 Commands 0 to 1 --- 1 F108 0 (Off)
040A Virtual Input 11 Commands 0 to 1 --- 1 F108 0 (Off)
040B Virtual Input 12 Commands 0 to 1 --- 1 F108 0 (Off)
040C Virtual Input 13 Commands 0 to 1 --- 1 F108 0 (Off)
040D Virtual Input 14 Commands 0 to 1 --- 1 F108 0 (Off)
040E Virtual Input 15 Commands 0 to 1 --- 1 F108 0 (Off)
040F Virtual Input 16 Commands 0 to 1 --- 1 F108 0 (Off)
0410 Virtual Input 17 Commands 0 to 1 --- 1 F108 0 (Off)
0411 Virtual Input 18 Commands 0 to 1 --- 1 F108 0 (Off)
0412 Virtual Input 19 Commands 0 to 1 --- 1 F108 0 (Off)
0413 Virtual Input 20 Commands 0 to 1 --- 1 F108 0 (Off)
0414 Virtual Input 21 Commands 0 to 1 --- 1 F108 0 (Off)
0415 Virtual Input 22 Commands 0 to 1 --- 1 F108 0 (Off)
0416 Virtual Input 23 Commands 0 to 1 --- 1 F108 0 (Off)
0417 Virtual Input 24 Commands 0 to 1 --- 1 F108 0 (Off)
0418 Virtual Input 25 Commands 0 to 1 --- 1 F108 0 (Off)
0419 Virtual Input 26 Commands 0 to 1 --- 1 F108 0 (Off)
041A Virtual Input 27 Commands 0 to 1 --- 1 F108 0 (Off)
041B Virtual Input 28 Commands 0 to 1 --- 1 F108 0 (Off)
041C Virtual Input 29 Commands 0 to 1 --- 1 F108 0 (Off)
041D Virtual Input 30 Commands 0 to 1 --- 1 F108 0 (Off)
041E Virtual Input 31 Commands 0 to 1 --- 1 F108 0 (Off)
041F Virtual Input 32 Commands 0 to 1 --- 1 F108 0 (Off)
0420 Virtual Input 33 Commands 0 to 1 --- 1 F108 0 (Off)
0421 Virtual Input 34 Commands 0 to 1 --- 1 F108 0 (Off)
0422 Virtual Input 35 Commands 0 to 1 --- 1 F108 0 (Off)
0423 Virtual Input 36 Commands 0 to 1 --- 1 F108 0 (Off)
Address Description Range Units Step Format Default
