10 D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
Table 10: Modbus memory map
Address Description Range Units Step Format Default
Product Information (Read Only)
0000 UR Product Type 0 to 65535 --- 1 F001 0
0002 Product Version 0 to 655.35 --- 0.01 F001 110
Product Information (Read Only - Written by Factory)
0010 Serial Number --- --- --- F203 “0”
0020 Manufacturing Date 0 to 4294967295 --- 1 F050 0
0022 Modification Number 0 to 65535 --- 1 F001 0
Product Information (Read Only Non-Volatile)
0023 Operating Time 0 to 4294967295 --- 1 F050 0
Product Information (Read Only - Written by Factory)
0040 Order Code --- --- --- F204 “Order Code
x”
0090 Ethernet MAC Address --- --- --- F072 0
0093 Reserved (13 items) --- --- --- F001 0
Communications Actual Values (Read Only)
0128 Modbus Available TCP/IP Connections 0 to 65535 --- --- F001 0
0129 MMS Available TCP/IP Connections 0 to 65535 --- --- F001 0
012A PMU Available TCP/IP Connections 0 to 65535 --- --- F001 0
012B IEC Available TCP/IP Connections 0 to 65535 --- --- F001 0
012C DNP Available TCP/IP Connections 0 to 65535 --- --- F001 0
0130 Port 1 Ethernet Actual Mode 0 to 2 --- 1 F192 0 (10/100
BASE-TX)
0131 Port 1 Ethernet Duplex 0 to 1 --- 1 F171 0 (Half
Duplex)
0132 Port 1 Ethernet Speed 0 to 1 --- 1 F170 0 (10 Mps)
0133 Port 1 Ethernet Link Status 0 to 1 --- 1 F155 0 (Offline)
0134 Port 2 Ethernet Actual Mode 0 to 2 --- 1 F192 0 (10/100
BASE-TX)
0135 Port 2 Ethernet Duplex 0 to 1 --- 1 F171 0 (Half
Duplex)
0136 Port 2 Ethernet Speed 0 to 1 --- 1 F170 0 (10 Mps)
0137 Port 2 Ethernet Link Status 0 to 1 --- 1 F155 0 (Offline)
0138 Port 3 Ethernet Actual Mode 0 to 2 --- 1 F192 0 (10/100
BASE-TX)
0139 Port 3 Ethernet Duplex 0 to 1 --- 1 F171 0 (Half
Duplex)
013A Port 3 Ethernet Speed 0 to 1 --- 1 F170 0 (10 Mps)
013B Port 3 Ethernet Link Status 0 to 1 --- 1 F155 0 (Offline)
013C Configure IP Network Status 0 to 19 --- 1 F173 0 (OK)
013D Active Port 1 IP Address 0 to 4294967295 --- 1 F003 0
013F Active Port 1 IP Subnet Mask 0 to 4294967295 --- 1 F003 0
0141 Active Port 1 Gateway IP Address 0 to 4294967295 --- 1 F003 0
0143 Active Port 2 IP Address 0 to 4294967295 --- 1 F003 0
0145 Active Port 2 IP Subnet Mask 0 to 4294967295 --- 1 F003 0
0147 Active Port 2 Gateway IP Address 0 to 4294967295 --- 1 F003 0
0149 Active Port 3 IP Address 0 to 4294967295 --- 1 F003 0
014B Active Port 3 IP Subnet Mask 0 to 4294967295 --- 1 F003 0
014D Active Port 3 Gateway IP Address 0 to 4294967295 --- 1 F003 0
