CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP
D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE 13
06CC Breaker 4 Operations B 0 to 4294967295 --- 1 F003 0
06CE Breaker 4 Operations C 0 to 4294967295 --- 1 F003 0
06D2 Breaker 5 Operations A 0 to 4294967295 --- 1 F003 0
06D4 Breaker 5 Operations B 0 to 4294967295 --- 1 F003 0
06D6 Breaker 5 Operations C 0 to 4294967295 --- 1 F003 0
06DA Breaker 6 Operations A 0 to 4294967295 --- 1 F003 0
06DC Breaker 6 Operations B 0 to 4294967295 --- 1 F003 0
06DE Breaker 6 Operations C 0 to 4294967295 --- 1 F003 0
Breaker Commands (Read/Write Command) (6 Modules)
06E0 Breaker 1 SCADA Command 0 to 15 --- 1 F107 0 (None)
06E1 Breaker 1 HMI Command 0 to 15 --- 1 F107 0 (None)
06E2 ...Repeated for Breaker 2
06E4 ...Repeated for Breaker 3
06E6 ...Repeated for Breaker 4
06E8 ...Repeated for Breaker 5
06EA ...Repeated for Breaker 6
Disconnect Actual Values (Read Only) (30 Modules)
06F0 Disconnect 1 SCADA AddCause 0 to 65535 --- 1 F500 0
06F1 Disconnect 1 HMI AddCause 0 to 65535 --- 1 F500 0
06F4 ...Repeated for Disconnect 2
06F8 ...Repeated for Disconnect 3
06FC ...Repeated for Disconnect 4
0700 ...Repeated for Disconnect 5
0704 ...Repeated for Disconnect 6
0708 ...Repeated for Disconnect 7
070C ...Repeated for Disconnect 8
0710 ...Repeated for Disconnect 9
0714 ...Repeated for Disconnect 10
0718 ...Repeated for Disconnect 11
071C ...Repeated for Disconnect 12
0720 ...Repeated for Disconnect 13
0724 ...Repeated for Disconnect 14
0728 ...Repeated for Disconnect 15
072C ...Repeated for Disconnect 16
0730 ...Repeated for Disconnect 17
0734 ...Repeated for Disconnect 18
0738 ...Repeated for Disconnect 19
073C ...Repeated for Disconnect 20
0740 ...Repeated for Disconnect 21
0744 ...Repeated for Disconnect 22
0748 ...Repeated for Disconnect 23
074C ...Repeated for Disconnect 24
0750 ...Repeated for Disconnect 25
0754 ...Repeated for Disconnect 26
0758 ...Repeated for Disconnect 27
075C ...Repeated for Disconnect 28
0760 ...Repeated for Disconnect 29
Address Description Range Units Step Format Default
