14 D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
0764 ...Repeated for Disconnect 30
Disconnect Operations Actual Values (Read Only Non-Volatile States) (30 Modules)
06F2 Disconnect 1 Operations 0 to 4294967295 --- 1 F003 0
06F6 Disconnect 2 Operations 0 to 4294967295 --- 1 F003 0
06FA Disconnect 3 Operations 0 to 4294967295 --- 1 F003 0
06FE Disconnect 4 Operations 0 to 4294967295 --- 1 F003 0
0702 Disconnect 5 Operations 0 to 4294967295 --- 1 F003 0
0706 Disconnect 6 Operations 0 to 4294967295 --- 1 F003 0
070A Disconnect 7 Operations 0 to 4294967295 --- 1 F003 0
070E Disconnect 8 Operations 0 to 4294967295 --- 1 F003 0
0712 Disconnect 9 Operations 0 to 4294967295 --- 1 F003 0
0716 Disconnect 10 Operations 0 to 4294967295 --- 1 F003 0
071A Disconnect 11 Operations 0 to 4294967295 --- 1 F003 0
071E Disconnect 12 Operations 0 to 4294967295 --- 1 F003 0
0722 Disconnect 13 Operations 0 to 4294967295 --- 1 F003 0
0726 Disconnect 14 Operations 0 to 4294967295 --- 1 F003 0
072A Disconnect 15 Operations 0 to 4294967295 --- 1 F003 0
072E Disconnect 16 Operations 0 to 4294967295 --- 1 F003 0
0732 Disconnect 17 Operations 0 to 4294967295 --- 1 F003 0
0736 Disconnect 18 Operations 0 to 4294967295 --- 1 F003 0
073A Disconnect 19 Operations 0 to 4294967295 --- 1 F003 0
073E Disconnect 20 Operations 0 to 4294967295 --- 1 F003 0
0742 Disconnect 21 Operations 0 to 4294967295 --- 1 F003 0
0746 Disconnect 22 Operations 0 to 4294967295 --- 1 F003 0
074A Disconnect 23 Operations 0 to 4294967295 --- 1 F003 0
074E Disconnect 24 Operations 0 to 4294967295 --- 1 F003 0
0752 Disconnect 25 Operations 0 to 4294967295 --- 1 F003 0
0756 Disconnect 26 Operations 0 to 4294967295 --- 1 F003 0
075A Disconnect 27 Operations 0 to 4294967295 --- 1 F003 0
075E Disconnect 28 Operations 0 to 4294967295 --- 1 F003 0
0762 Disconnect 29 Operations 0 to 4294967295 --- 1 F003 0
0766 Disconnect 30 Operations 0 to 4294967295 --- 1 F003 0
Disconnect SCADA Commands (Read/Write Commands) (30 Modules)
0770 Disconnect 1 SCADA Command 0 to 15 --- 1 F107 0 (None)
0771 Disconnect 1 HMI Command 0 to 15 --- 1 F107 0 (None)
0772 ...Repeated for Disconnect 2
0774 ...Repeated for Disconnect 3
0776 ...Repeated for Disconnect 4
0778 ...Repeated for Disconnect 5
077A ...Repeated for Disconnect 6
077C ...Repeated for Disconnect 7
077E ...Repeated for Disconnect 8
0780 ...Repeated for Disconnect 9
0782 ...Repeated for Disconnect 10
0784 ...Repeated for Disconnect 11
0786 ...Repeated for Disconnect 12
0788 ...Repeated for Disconnect 13
Address Description Range Units Step Format Default
