CHAPTER 2: MODBUS COMMUNICATION MODBUS MEMORY MAP
D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE 15
078A ...Repeated for Disconnect 14 0 to 15 --- 1 F107 0 (None)
078C ...Repeated for Disconnect 15 0 to 15 --- 1 F107 0 (None)
078E ...Repeated for Disconnect 16 0 to 15 --- 1 F107 0 (None)
0790 ...Repeated for Disconnect 17 0 to 15 --- 1 F107 0 (None)
0792 ...Repeated for Disconnect 18 0 to 15 --- 1 F107 0 (None)
0794 ...Repeated for Disconnect 19 0 to 15 --- 1 F107 0 (None)
0796 ...Repeated for Disconnect 20 0 to 15 --- 1 F107 0 (None)
Disconnect SCADA commands (read/write commands, 30 modules)
0770 Disconnect 1 SCADA command 0 to 15 --- 1 F107 0 (None)
0772 Disconnect 2 SCADA command 0 to 15 --- 1 F107 0 (None)
0774 Disconnect 3 SCADA command 0 to 15 --- 1 F107 0 (None)
0776 Disconnect 4 SCADA command 0 to 15 --- 1 F107 0 (None)
0778 Disconnect 5 SCADA command 0 to 15 --- 1 F107 0 (None)
077A Disconnect 6 SCADA command 0 to 15 --- 1 F107 0 (None)
077C Disconnect 7 SCADA command 0 to 15 --- 1 F107 0 (None)
077E Disconnect 8 SCADA command 0 to 15 --- 1 F107 0 (None)
0780 Disconnect 9 SCADA command 0 to 15 --- 1 F107 0 (None)
0782 Disconnect 10 SCADA command 0 to 15 --- 1 F107 0 (None)
0784 Disconnect 11 SCADA command 0 to 15 --- 1 F107 0 (None)
0786 Disconnect 12 SCADA command 0 to 15 --- 1 F107 0 (None)
0788 Disconnect 13 SCADA command 0 to 15 --- 1 F107 0 (None)
078A Disconnect 14 SCADA command 0 to 15 --- 1 F107 0 (None)
078C Disconnect 15 SCADA command 0 to 15 --- 1 F107 0 (None)
078E Disconnect 16 SCADA command 0 to 15 --- 1 F107 0 (None)
0790 Disconnect 17 SCADA command 0 to 15 --- 1 F107 0 (None)
0792 Disconnect 18 SCADA command 0 to 15 --- 1 F107 0 (None)
0794 Disconnect 19 SCADA command 0 to 15 --- 1 F107 0 (None)
0796 Disconnect 20 SCADA command 0 to 15 --- 1 F107 0 (None)
0798 Disconnect 21 SCADA command 0 to 15 --- 1 F107 0 (None)
079A Disconnect 22 SCADA command 0 to 15 --- 1 F107 0 (None)
079C Disconnect 23 SCADA command 0 to 15 --- 1 F107 0 (None)
079E Disconnect 24 SCADA command 0 to 15 --- 1 F107 0 (None)
07A0 Disconnect 25 SCADA command 0 to 15 --- 1 F107 0 (None)
07A2 Disconnect 26 SCADA command 0 to 15 --- 1 F107 0 (None)
07A4 Disconnect 27 SCADA command 0 to 15 --- 1 F107 0 (None)
07A6 Disconnect 28 SCADA command 0 to 15 --- 1 F107 0 (None)
07A8 Disconnect 29 SCADA command 0 to 15 --- 1 F107 0 (None)
07AA Disconnect 30 SCADA command 0 to 15 --- 1 F107 0 (None)
0798 ...Repeated for Disconnect 21 0 to 15 --- 1 F107 0 (None)
079A ...Repeated for Disconnect 22 0 to 15 --- 1 F107 0 (None)
079C ...Repeated for Disconnect 23 0 to 15 --- 1 F107 0 (None)
079E ...Repeated for Disconnect 24 0 to 15 --- 1 F107 0 (None)
07A0 ...Repeated for Disconnect 25 0 to 15 --- 1 F107 0 (None)
07A2 ...Repeated for Disconnect 26 0 to 15 --- 1 F107 0 (None)
07A4 ...Repeated for Disconnect 27 0 to 15 --- 1 F107 0 (None)
07A6 ...Repeated for Disconnect 28 0 to 15 --- 1 F107 0 (None)
07A8 ...Repeated for Disconnect 29 0 to 15 --- 1 F107 0 (None)
Address Description Range Units Step Format Default
