2.1 GENERAL 2 CALCULATION OF SETTINGS
2
303 TL14 1 to 9 sec. 1
CURRENT UNBALANCE – TRIP: 46T
401 TRIP 0000 to 1111 N/A 0000
402 ALARM 0000 to 1111 N/A 0000
403 PICKUP 0.05 to 2.99 0.01 to 0.60 A 2.00 0.40
404 K2 1.0 to 45.0 sec. 1.0
LOSS OF EXCITATION – SUPERVISION: 40
501 SELV2SUP DISABLE (0); ENABLE (1) N/A DISABLE
LOSS OF EXCITATION – ZONE 1: 40-1
601 TRIP 0000 to 1111 N/A 0000
602 ALARM 0000 to 1111 N/A 0000
603 CENTER 2.50 to 60.00 12.5 to 300.00
Ω
11.00 55.00
604 RADIUS 2.50 to 60.00 12.5 to 300.00
Ω
8.50 42.50
605 TL12 0.01 to 9.99 sec. 0.01
LOSS OF EXCITATION – ZONE 2: 40-2
701 TRIP 0000 to 1111 N/A 0000
702 ALARM 0000 to 1111 N/A 0000
703 CENTER 2.50 to 60.00 12.50 to 300.0
Ω
11.00 55.00
704 RADIUS 2.50 to 60.00 12.50 to 300.0
Ω
8.50 42.50
705 TL13 0.01 to 9.99 sec. 0.01
ANTI-MOTORING #1: 32-1
801 TRIP 0000 to 1111 N/A 0000
802 ALARM 0000 to 1111 N/A 0000
803 SQ TR EN YES [1/Y]; NO [3/N] N/A YES
804 REV PWR 0.5 to 99.9 0.1 to 19.9 W 1.5 0.3
805 TL1 1 to 120 sec. 5
ANTI-MOTORING #2: 32-2
901 d TRIP 0000 to 1111 N/A 0000
Table 2–1: DGP SYSTEM SETTINGS & RATINGS (Sheet 2 of 7)
SETTING
NUMBER
MNEMONIC RANGE DEFAULT
5 AMP 1 AMP UNITS 5 AMP 1 AMP
c
