GE Power Management DGP Digital Generator Protection System 2-
51
2 CALCULATION OF SETTINGS 2.4 COMMISSIONING
2
2.4.3 DGP
***
ACA SETTINGS TABLE
Table 2–7: DGP
***
ACA SETTINGS TABLE (Sheet 1 of 6)
LOCATION: GENERATOR NUMBER:
RELAY MODEL NUMBER: DGP _ _ _ ACA PROM VERSION NUMBER: V _ _ _ . _ _ _ _ _ D
SETTING # MNEMONIC DESCRIPTION USER SETTING
CONFIGURATION: CONFIG
101 UNITID Unit ID number
102 SYSFREQ System Frequency Hz
103 SEL TVM Select Trip Voltage Monitoring
104 SEL TCM Select Trip Current Monitoring
105 SELPRIM Select Primary/Secondary units
106 CT RATIO Current Transformer Ratio
107 VT RATIO Voltage Transformer Ratio
108 COMMPORT Communications Port
109 PHASE Phase Rotation
110 TIMESYNC Time Synchronizing source
111 NUM FLTS Number of Fault events stored
112 PREFLT Number of prefault cycles stored Cycles
113 OSC TRIG External oscillography trigger
114 NOM VOLT Nominal Voltage of generator Volts
115 RATEDCUR Rated Current of generator Amps
116 VT CONN Type of VT connection
117 NCTRATIO Current Transformer Ratio (Neutral)
STATOR DIFFERENTIAL: 87G
201 TRIP Configure trip outputs
202 ALARM Configure alarm outputs
203 K1 K factor %
204 PICKUP Pickup level Amps
CURRENT UNBALANCE – ALARM: 46A
301 ALARM Configure alarm outputs
302 PICKUP Pickup current (Negative sequence) Amps
303 TL14 Timer TL14 setting Sec.
