Installation Instructions
BOTTOM DRAWER
STEP 8 REPLACE THE FREEZER
DRAWERS (CONT.)
ATTACH AND SECURE THE DRAWER FRONT
TO THE SLIDES
A.
Pull out the rail assemblies to the full length
on each side of the cabinet.
B. Drive the top screw into the door on each side until
it is 1/2 way in.
C. Hang the drawer front onto the open slots on
the slides.
D. Drive the screws fully.
(There are 10 screws, 5 on each side.)
Drive screws
in these holes.
Line up
screw hole
in freezer
drawer and
drive fully.
Step D1:
Step D2:
REPLACE THE FREEZER BASKET
• Replace the bottom drawer freezer basket by
lowering it into the frame.
10
STEP 8 REPLACE THE FREEZER
DRAWERS (CONT.)
