RSTi-EP Slice I/O Serial Communication Module 7
GFK-2992B
Process Output Data
QB0
Word
Status and
Diagnosis
IX0.0 RXBUF FLUSH
The receive memory can be scrubbed using
this bit.
STATRES = 1: A requirement with RXBUF FLUSH
= 1 will be ignored.
STATRES = 0: The receive memory will be
scrubbed with RXBUF FLUSH = 1.
IX0.1 TXBUF FLUSH
The emission memory can be scrubbed using
this bit.
STATRES = 1: A requirement with TXBUF FLUSH
= 1 will be ignored.
STATRES = 0: The emission memory will be
scrubbed with TXBUF FLUSH = 1.
IX0.2 RX_HWBUFFER
Bit 2: DisableSend_TX_HWBUFFER
This bit controls the hardware emission
memory:
DisableSend_TX_HWBUFFER = 0: The hardware
emission memory is released. A character
(Byte) will be sent as soon as it reaches the
buffer.
DisableSend_TX_HWBUFFER = 1: The hardware
emission memory is locked. Characters (Bytes)
will only be sent, when
DisableSend_TX_HWBUFFER is set to 0 again.
IX0.3 TX_CNT
The TX_CNT value is assigned to each data
segment of the process output data. The
sequence or the TX_CNT values is:
Binary: 00–>01–>10–>11–>00...
Decimal: 0–>1–>2–>3–>0...
A faulty data sequence indicates missing data
IX0.4 TX_CNT
IX0.5 RX_CNT_ACK
RX_CNT_ACK must include a copy of the
RX_CNT value. The RX_CNT value has been
transferred together with the last data
segment of the process input data.
RX_CNT_ACK must be set in analogy with
RX_CNT (in the status byte). It indicates that the
data segment has been transferred
successfully by using RX_CNT and enables to
IX0.6 RX_CNT_ACK
IX0.7
Communication
Status
The input data status bit STAT will be reset
using this bit. When changing from 1 to 0
(falling edge) STAT will be reset from 0 to 1.
STAT = 0: All changes in the data fields
TX_BYTE_CNT, TX_CNT and RX_CNT_ACK will be
ignored. The receive or emission memory can
be scrubbed using RXBUF FLUSH or TXBUF
FLUSH respectively.
STAT = 1 or changing from 0 to 1: The buffers
QB1 Word
Length of the
data segment
or
Transmission
data
transferred
