Loading place settings…
Follow these guidelines for loading 10 place settings. Features and appearance of racks and silverware baskets
may vary from your model.
NOTE:
Silverware should be individually loaded into the slots on the silverware basket lid.
Upper Rack—10 place settings (on some models) Lower Rack—10 place settings (on some models)
Follow these guidelines for loading 12 place settings. Features and appearance of racks and silverware baskets
may vary from your model.
NOTE:
Silverware should be individually loaded into the slots on the silverware basket lid.
Upper Rack—12 place settings (on some models) Lower Rack—12 place settings (on some models)
9
Front Control models
with square basket
Front Control models
with square basket
Front Control models
with square basket
Front Control models
with square basket
Long silverware basket
models
*Tine finger: Vertical wire that separates and holds plates on the rack.
*Tine finger: Vertical wire that separates and holds plates on the rack.
Long silverware basket
models
Long silverware basket
models (12 tine
fingers* by row)
Long silverware basket
models (12 tine
fingers* by row)
Long silverware basket
models (13 tine
fingers* by row)
Long silverware basket
models (13 tine
fingers* by row)
NOTE: Do not place plates smaller than 6” on the back of the lower rack, refer to figures shown above.
