– 49 –
3. Straighten the 2 tabs and remove the terminal
guard.
2. Carefully pull the upper element Styrofoam
insert straight out.
Styrofoam Insert
Terminal Guard
Reset
4. Mark, then disconnect the wires from the TCO.
5. Lift each of the 2 clips that hold the TCO to the
tank and pull the TCO up.
Clip
Clip
TCO
Tab
Tab
