GE GSMF2LEB User Manual

Installation Instructions
CONNECT
ING THE REFRIGERATOR
TO THE HOUSE WATER LINE
(icemaker and dispenser models)
A
cold
water
supply
is
required
for
automatic
icemaker and dispenser
operation. If there is not a cold water
supply , you will need to provide one.
See “Installing the Water Line” section.
NOTES:
• Before making the connection to the
refrigerator , be sure the refrigerator
power cord is not plugged into the wall
outlet.
• If your refrigerator does not have a
water lter , we recommend installing
one if your water supply has sand or
particles that could clog the screen of
the refrigerator’ s water valve. Install it
in the water line near the refrigerator.
If using GE SmartConnect
™
Refrigerator
Tubing Kit, you will need an additional
tube (WX08X10002) to connect the lter.
Do not cut plastic tube to install lter.
If you are using copper tubing, place a
compression nut and ferrule (sleeve) onto
the end of the tubing coming from the
house cold water supply.
If you are using the GE Smar tConnect
™
tubing, the nuts are already assembled to
the tubing.
If
you are using copper tubing, insert
the end of the tubing into the refrigerator
connection, at the back of the refrigerator,
as far as possible. While holding the
tubing, tighten the tting.
If you are using GE SmartConnect
™
tubing, insert the molded end of the
tubing into
the refrigerator connection,
at the back of the refrigerator , and tighten
the compression nut until it is hand tight.
Then tighten one additional turn with a
wrench. Overtightening may cause leaks.
1
A
B
Fasten the tubing into the clamp provided
to
hold it in position. You may need to pry
open the clamp.
1/4" Tubing
Tubing C
lamp
1/4"
Compres
sion Nut
F
e
r
r
u
l
e
(
sleeve)
SmartConnect
™
Tubing
Refrige
rator
Connection
C
TURN ON THE WATER SUPPL
Y
Turn the water on at
the shuto valve
(house water supply) and check for
any leaks.
2
PLUG IN THE REFRIGERATOR
Before
plugging
in
the
refrigerator
,
make
sure
the icemaker power switch is set to
the O (o) position.
See the grounding information attached
to the power cord.
3
NOTE: The image can be dierent from your product.
