BASIC OPERATION AND FEATURES
SX TRANSISTOR CONTROL Page 12
January 1999
Function 14 similar to SLl. PIA will close 0.2 seconds after
controlled acceleration stops. Speed Limit 4 (Function 14)
must be activated and set to >250 to enable the optional P 1
A contactor.
If more than one Speed Limit is activated, the selected
speed with the highest motor volts will override the low
motor volt speed. The current limit circuit is adjustable and
operates the same as the traction current limit.
The controlled acceleration circuit is adjustable and
operates the same as the traction circuit. Adjustment range
is from 0.1 to 5.5 seconds.
The variable resistor input will override the fixed motor volt
limits set by the four (4) adjustable Speed Limits. It will vary
motor volts above the set limits up to full motor volts, and
closes P1A as resistance is decreased to less than 200
ohms.
The Battery Discharge Indicator (BDI) interrupt will disable
the hydraulic controller if the connection at P10 loses the
12 volt signal from the traction control. BDI interrupt can be
disabled by Function 17 using the Handset. Select card type
with or without BDI function.
