10 GEI-100268
Table 7. Plug P1 Pin Assignments, Row D
Pin No. Nomenclature Definition
D1, D3, D5,
D7, D9, D11,
D13, D15,
D31, D32
NC Not Connected
D2 DIN1A Differential digital input 1
D4 DIN2B Differential digital input 2
D6 DIN4A Differential digital input 4
D8 DIN5B Differential digital input 5
D10 P12
Isolated +12, 12 V dc power source
D12 COM12
±12Vdc isolated power return (common)
D14 N12
Isolated +12, 12 V dc power source
D16 ENCAP Differential encoder input A
D17 ENCAN Differential encoder input A
D18 DT(M) Differential transmit A
D19 DT(MB) Differential transmit B
D20 AIN1P Analog input 1 differential input (also burden resistor input)
D21 AIN1N Analog input 1 differential input (also burden resistor input)
D22 ACOM Analog common – for outputs 1 & 2
D23 POT_N P12/N12 supplied to user for powering a potentiometer
D24 K232RTS Keypad RS232 RTS signal
D25 T232TXEN Tool RS232 TX signal
D26 GR_A(TX–) ISBus "A" TX signal
D27 GR_A(RX–) ISBus "A" RX signal
D28 GR_B(TX–) ISBus "B" TX signal
D29 GR_B(RX–) ISBus "B" RX signal
D30 P18 +18 V
