Burner cap properly seated
€
Burner cap not properly seated
Burner Head and Cap Replacement
Replacethe burner head onto the burner base,
making surethat the head is properly oriented
overthe burner base and the electrode. Make
sureto place the correct burner head on the
correct burner baseand that the burner head
sitslevel on the burner base.The burner heads
are not interchangeable.
Replacethe burner cap onto the burner head,
making sureto place the correct burner cap on
the correct burner head. Theburner caps are
not interchangeable.Also,make sure that the
burner caps are properly seated on the burner
heads.
JGP940 and JGP970 Kollburners)
Burner cop
Burner head
indentations
base
Make sure the pins in the burner heads match
the burner base indentations and that they are
properly seated in them by rotating the heads
until they are level
JGP329, JGP333, PGP943 and
PGP966
L _
Burner base
Makesure the slotin the burner head ispositioned
over the electrode. Theburner cap has three
to four pins. When replacing the cap, make sure
none of thepins sits in the stability chamber.
JGP333, PGP943 and PGP966
flight front burner onlg)
Burner cap
Burner head,/_
assembly _ Orifice
Electrode base
Makesure the hole in the burner head assembly
ispositioned over the electrode and that the burner
head is fully inserted inside the burner base.A small
gap between the base and head is normal
(On some models)
"OUTSIDE.... INSIDE.... OUTSIDE"
edge edges edge
(On some models)
"INSIDE"
edges
I
"OUTSIDE"
edge
Tabs
Burner Grates
Your cooktop has professional style grates.
Thesegrates are designedfor specific
positions.Thesegrates should only be used
in their proper positions;they should not be
interchanged. Foryour convenience, the
undersidesof
the left and right grates are marked "OUTSIDE"
and "INSIDE".Makesurethat the sidesmarked
"OUTSIDE"are facing the outer edge of the
cooktop and the sidesmarked "INSIDE"are
facing eachother. All grates should
touch once they are
fully assembledon the
cooktop surface.
"OUTSIDE"
edge
Forcooktops with three grates, make
surethat the tabs on either side of
the center grate fit into the slots
located on the "INSIDE"edge of the
sidegrates.
Liftthe burner grates out only when cool.
Grates should be washed regularly and, of
course,after spillovers.Wash them in the
dishwasher or in hot, soapy water and rinse
with cleanwater. When replacing the grates,
be sure they are positioned securely overthe
burners.
Although they are durable,the grates will
gradually lose their shine, regardless of the
best careyou can give them. Thisis due to their
continual exposure to high temperatures. You
will notice this sooner with lighter color grates.
Donot operate a burner for an extended period
of time without cookware on the grate. The
finish on the grate may chip without cookware
to absorb the heat.
NOTE:Do not cleanthe grates in a self-cleaning
oven.
