Installation Instructions
SECURE THE OVEN
IMPORTANT:
Remove
all packing material and literature
from the oven before connecting
any electrical supplies.
Using a 1/8
″
drill bit, drill holes through the
side trim and into the cabinet front.
With the screws provided, secure the oven
to the wall.
If the cabinet cutout is 38
″
high, use the
short trim and attach to the bottom of the
front frame, with screws provided.
(If the cutout is higher than 38
″,
use the taller trim.)
C
B
A
10
RECHECK STEPS
Double check to make sure everything in this
guide has been completed. Rechecking steps will
ensure safe use of the oven.
WARNING:
The trim permits air
entry into the cabinet below the unit and
must not be blocked.
