5
Cabinet Width 27”
Recommended
Minimum
Cutout Location
from Floor 21 5/8”
Cutout Depth 23 1/2”
Cutout Width 25” Min.
25 1/4” Max.
Cutout Height 41 1/8” Min.
41 1/4” Max.
If the cabinet does not have a solid bottom,
two braces or runners must be installed
level with the bottom of the cutout to
support the weight of the oven. The
runners and braces must support 255 lbs.
Installation Instructions
NOTE: If the cabinet does not
have a front frame and the
sides are less than 3/4” thick,
shim both sides equally to
establish the cutout width.
Cutout for Built-In Oven
with Microwave
A
18"
27"
24"
2" x 4" or
Equivalent
Runners
24”
18”
27”
2” x 4” or equivalent
runners level with
bottom of cutout
NOTE: If using equivalent
runners, then the center of the
equivalent runners should be
20 1/2”.
NOTE: If marks, blemishes or the
cutout opening are visible above the
installed oven, it may be necessary to
add wood shims under the runners and
front trim until the marks or opening
are covered.
CUTOUT
WIDTH
25" MIN.
25 1/4" MAX.
10"
48"
5"
JUNCTION BOX
LOCATION
To bottom
of junction box
CABINET
WIDTH
27"
Allow a minimum of 20"
for clearance to adjacent
corners, drawers, walls, etc.
when doors are open
Allow 7/8"
for overlap of
oven over side
edges of cutout
Allow 1" for
overlap of oven
top and bottom
of cutout
CUTOUT
HEIGHT
41 1/8" MIN.
41 1/4" MAX.
Recommended
cutout location
from floor
21 5/8"
20"
2" x 4"
or
equivalent
runners
Alternate
junction box
location
20”
5”
Junction Box
Location
10”
Recommended
minimum cutout location
from floor 21 5/8”
Alternate
Junction Box
Location
44”
Above
base rail
Cabinet
Width
27”
Allow minimum
1” for overlap
of oven top and
bottom of cutout
2” x 4” or
equivalent
runners
level with
bottom
of cutout
Allow a minimum of 20”
for clearance to adjacent
corners, drawers, walls,
etc. when door is open
Allow 7/8” for
overlap of oven
over side edges
of cutout
Cutout
Height
41 1/8” Min.
41 1/4” Max.
Cutout
Width
25” Min.
25 1/4” Max.
