5
Installation Instructions
PREPARE THE COUNTER (CONT.)
If you are using the Filler or Backguard:
NOTE: If the distance from the back wall
to the front of the counter backsplash
(Dimension A in Fig. 11) is greater than the
standard 1-1/8″, there will be a small gap
between the wall behind the range and the
backguard. This is normal and should not
be visually objectionable.
5
SIDE TRIM EXTENSION KIT
If there is a small gap between the sides of
the range and the cabinets (up to 1/4″ each
side), you can order a side trim extension kit,
Pub, #3-A040, through the GE service center.
6
25”
30”
A
Fig. 11
Fig. 10
To Next Page
