Control Network (UDH)
System Building Blocks
Controller
3 IONET Ports
2 Control Network Ports
1 COM Port
IONET Switch
I/O Module
I/O Pack
• Local Processor
• Data Acquisition
Terminal Block
Typical Mark VIe Architecture
Instruction Guide GEI-100728A 5
