NX-7002 PROGRAMMING WORKSHEETS
(Factory defaults are in bold italic text)
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
MODE OF OPERATION FEATURE SELECTION
Segment 1 (Circle Numbers To Program) Segment 2 (Circle Numbers To Program)
1 Enable site initiated downloading (*98 from a
keypad)
1 Use SIA DCS as backup format (Contact ID if off)
2 Enable remote initiated downloading 2 Reserved
3 Remote initiated download must be from
known source
3 Reserved
4 Enable remote download at test time 4 Reserved
5 Enable auto-answer incoming CSD GSM
download call
5 Reserved
6 Callback required for incoming CSD GSM
download call
6 Reserved
7 Use V.110 for site-initiated CSD GSM calls 7 Reserved
13
8 Use non-transparent mode for site initiated
CSD GSM calls
8 Reserved
Segment 3 (Circle Numbers To Program) Segment 4 (Circle Numbers To Program)
1 Reserved 1 Reserved
2 Polling enable (for UL AA) 2 Reserved
3 Reserved 3 Reserved
4 Reserved 4 TCP/IP Reporting in SIA (Contact ID if off)
5 Reserved 5 Reserved
6 Reserved 6 Reserved
7 Reserved 7 Reserved
0
13
8 Reserved 8 Reserved
1 14 DESTINATION SELECTION FOR REPORT CONTROL 1 0
2 14 BACKUP DESTINATION SELECTION FOR REPORT
CONTROL 1
0
3 14 REPORT DELAY FOR REPORT CONTROL 1 0
EVENT SELECTION FOR REPORT CONTROL 1 (BY PARTITION)
Segment 1 Alarms and Restores 1-2-3-4-5-6-7-8
Segment 2 Open/Close 1-2-3-4-5-6-7-8
Segment 3 Bypass 1-2-3-4-5-6-7-8
Segment 4 Zone Trouble 1-2-3-4-5-6-7-8
Segment 5 Power Trouble (AC Failure / Low Batt.) 1-2-3-4-5-6-7-8
Segment 6 Siren & Telephone Fault 1-2-3-4-5-6-7-8
Segment 7 Test Reports 1-2-3-4-5-6-7-8
Segment 8 Program, Download, & Log Full 1-2-3-4-5-6-7-8
Segment 9 Tampers (zones and box) 1-2-3-4-5-6-7-8
Segment 10 Short Circuit 1-2-3-4-5-6-7-8
Segment 11 Sensor Lost 1-2-3-4-5-6-7-8
Segment 12 Sensor Low Battery 1-2-3-4-5-6-7-8
Segment 13 Expander Trouble (incl. keypad) 1-2-3-4-5-6-7-8
Segment 14 Failure To Communicate 1-2-3-4-5-6-7-8
Segment 15 Zone Activity Monitoring 1-2-3-4-5-6-7-8
4 15
Segment 16 Reserved 1-2-3-4-5-6-7-8
5 15 DESTINATION SELECTION FOR REPORT CONTROL 2 0
6 15 BACKUP DESTINATION SELECTION FOR REPORT
CONTROL 2
0
7 15 REPORT DELAY FOR REPORT CONTROL 2 0
NX-7002 Installation manual Page 26 09/02/05
