LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
EVENT SELECTION FOR REPORT CONTROL 6 (BY PARTITION)
Segment 1 Alarms and Restores 0-0-0-0-0-0-0-0
Segment 2 Open/Close 0-0-0-0-0-0-0-0
Segment 3 Bypass 0-0-0-0-0-0-0-0
Segment 4 Zone Trouble 0-0-0-0-0-0-0-0
Segment 5 Power Trouble (AC Failure / Low Batt.) 0-0-0-0-0-0-0-0
Segment 6 Siren & Telephone Fault 0-0-0-0-0-0-0-0
Segment 7 Test Reports 0-0-0-0-0-0-0-0
Segment 8 Program, Download, & Log Full 0-0-0-0-0-0-0-0
Segment 9 Tampers (zones and box) 0-0-0-0-0-0-0-0
Segment 10 Short Circuit 0-0-0-0-0-0-0-0
Segment 11 Sensor Lost 0-0-0-0-0-0-0-0
Segment 12 Sensor Low Battery 0-0-0-0-0-0-0-0
Segment 13 Expander Trouble (incl. keypad) 0-0-0-0-0-0-0-0
Segment 14 Failure To Communicate 0-0-0-0-0-0-0-0
Segment 15 Zone Activity Monitoring 0-0-0-0-0-0-0-0
24 17
Segment 16 Reserved 0-0-0-0-0-0-0-0
PRIMARY REPORTING FLAGS FOR REPORT CONTROL 1 TO 6
Segment 1 (Circle Numbers To Program)
1 On = Report Control 1 is Primary Reporting Flag / Off = Report Control 1 is Backup for control panel
2 On = Report Control 2 is Primary Reporting Flag / Off = Report Control 2 is Backup for control panel
3 On = Report Control 3 is Primary Reporting Flag / Off = Report Control 3 is Backup for control panel
4 On = Report Control 4 is Primary Reporting Flag / Off = Report Control 4 is Backup for control panel
5 On = Report Control 5 is Primary Reporting Flag / Off = Report Control 5 is Backup for control panel
6 On = Report Control 6 is Primary Reporting Flag / Off = Report Control 6 is Backup for control panel
7 Reserved
25 17
8 Reserved
26 - 31 17 RESERVED
32 18 PPP (dial-up account) user ID (chars 1 - 16)
---------------
33 18 PPP (dial-up account) user ID (chars 17 - 32)
---------------
34 18 PPP (dial-up account) password
---------------
35 – 59 18 RESERVED
60 18 Name of GPRS access point - APN (chars 1 - 16)
---------------
61 18 Name of GPRS access point - APN (chars 17 - 32)
---------------
62 18 Name of GPRS access point - APN (chars 33 - 48)
---------------
63 18 Name of GPRS access point - APN (chars 49 - 64)
---------------
64 - 100 18 RESERVED
101 19 NX-7002 assigned IP address (DHCP) 0.0.0.0
102 19 IP address for TCP/IP receiver 1 0.0.0.0
103 19 IP address for TCP/IP receiver 2 0.0.0.0
104-118 19 RESERVED
119 19 Receiver alarm and poll port 9.9.9.9
120-138 19 RESERVED
139 19 TCP/IP 1 Account number 0-0-0-0-1-0-0-0
140 19 TCP/IP 1 Receiver number 0-0-0-1
141 19 TCP/IP 1 Line number 0-0-0-1
142 19 TCP/IP 2 Account number 0-0-0-0-1-0-0-0
143 19 TCP/IP 2 Receiver number 0-0-0-1
144 19 TCP/IP 2 Line number 0-0-0-1
145 20 SMS 1 Account number 0-0-0-0-0-0-0-0
146 20 SMS 2 Account number 0-0-0-0-0-0-0-0
147-153 20 RESERVED
NX-7002 Installation manual Page 29 09/02/05
