33
ge.com
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Lift-Off Lower Oven Door
The door is very heavy. Be careful when
removing and lifting the door.
Do not lift the door by the handle.
To remove the door:
Fully open the door.
Pull the hinge locks down toward
the door frame, to the unlocked
position. A tool, such as a small
flat-blade screwdriver, may be
required.
Firmly grasp both sides of the door
at the top.
Close door to the door removal
position, which is halfway between
the broil stop position and fully
closed.
Lift door up and out until the hinge
arm is clear of the slot.
To replace the door:
Firmly grasp both sides of the door
at the top.
With the
door at the
same angle as
the removal
position, seat the
indentation of
the hinge arm
into the bottom
edge of the hinge slot. The notch in
the hinge arm must be fully seated
into the bottom of the slot.
Fully open the door. If the door will
not fully open, the indentation is not
seated correctly in the bottom edge
of the slot.
Push the hinge locks up against the
front frame of the oven cavity to the
locked position.
Close the oven door.
Indentation
Bottom
edge
of slot
Hinge arm
Removal position
Hinge
lock
Hinge
lock
Slot
Push hinge locks up to lock.
Pull hinge locks down to unlock.
Hinge
arm
