– 68 –
Ice Bucket
Ice Bucket
The bucket can be removed by pulling the door
latch down, opening the ice box door, then lifting
and pulling the bucket out.
Door Latch
L
I
F
T
The door latch is attached to the ice box door with 2
Phillips-head screws.
The door gasket is secured to the door by a barbed
edge that locks into a retainer channel.
To remove and replace the door gasket:
1. Starting at any corner, pull the old gasket out of
the retaining channel.
2. Soak the new gasket in warm water to make it
pliable.
3. Push the barbed edge of the gasket into the
retainer channel.
(Continued next page)
