Preparing to install the refrigerator.
Door Alignment
After leveling, make sure that doors are even at the top.
To make the doors even,
adjust the fresh food door. Insert a 3/16² Allen wrench into the bottom of the
hinge pin. Turn the door adjusting screw to the right to raise the door, to the left to lower it. (A nylon plug,
imbedded in the threads of the pin, prevents the pin from turning unless a wrench is used.) After one or two
turns of the wrench, open and close the fresh food door and check the alignment at the top of the doors.
Dimensions and Specifications
(for Built-In Style models)
Remove base grille by opening
the doors and pulling the grille
straight out.
3/16² Allen Wrench
70
1
/
4
²
36²
24²
24² Cabinet
24² Side Panels
Water Electrical
3/4² Airspace
(1/2² Gap + 1/4²
Wall Plates)
25²
Counter Top
