GE Profile GVE Series User Manual

49-1000332 Rev. 4 25
INSTALLATION INSTRUCTIONS
2
REMOVE REFRIGERATOR DOORS
(cont)
For proper installation later, please follow
these next steps carefully:
Ŷ Remove the tape keeping the door as straight as
possible, then lift up to remove.
CAUTION
Lifting Hazard.
A single person lift could cause injury. Gain
assistance when handling, moving, or lifting
refrigerator doors.
3
REMOVE THE RIGHT-HAND DOOR
Ŷ Remove right hinge cover.
Ŷ Securely tape the door shut with masking tape or
have a second person support the door.
Ŷ5HPRYHVFUHZVKROGLQJKLQJHZLWKD´VRFNHW
Lift hinge from refrigerator and door.
For proper installation later, please follow
these next steps carefully:
Ŷ Remove the tape keeping the door as straight as
possible, then lift up to remove.
CAUTION
Lifting Hazard.
A single person lift could cause injury. Gain
assistance when handling, moving, or lifting
refrigerator doors.
To reassemble doors, reverse removal steps.
4
REMOVE CENTER HINGE (if necessary)
Remove screws that secure hinge to the cabinet.
,QQHUVFUHZVQHHGD´VRFNHW2XWHUVFUHZ
needs a Phillips #2.
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
2
REMOVE THE LEFT-HAND DOOR
WARNING
)ROORZDOOVWHSVIRUUHPRYLQJ
DQGUHLQVWDOOLQJWKHGRRU)DLOXUHWRIROORZWKHVH
instructions, leaving off parts, or overtightening
screws, can lead to the door falling off and result in
injury and property damage.
Ŷ/RRVHQWKHLFHPDNHUZDWHUVXSSO\WXEH
Ɣ/RRVHQDQGUHPRYHWKHWXELQJFODPSZKLFK
holds the water supply tube to the back of the
refrigerator.
Ɣ5HPRYHWKHWRSEODFNFROODUIURPZDWHUVXSSO\
tube connector at the top right back of the
refrigerator.
Ɣ3UHVVWKHZKLWHIODQJHGRZQDQGVHSDUDWHWKH
water supply line from the connector.
Ŷ5HPRYHWKHOHIWKLQJHFRYHUE\UHPRYLQJKLQJH
cover screws with a Phillips head screwdriver
DQGOLIWLQJIURPWKHOHIWVLGH'LVFRQQHFWHOHFWULFDO
connectors and pull the water supply tube through
the case.
Ŷ6HFXUHO\WDSHWKHGRRUVKXWZLWKPDVNLQJWDSHRU
have a second person support the door.
Ŷ5HPRYHVFUHZVKROGLQJKLQJHZLWKD´VRFNHW
Lift hinge from refrigerator and door.
Collar
Connector
Water Supply Tube
Tubing Clamp
Electrical
Connections
Hinge
Screws
Ground
Screws
Remove
center screw
Loosen outer
screws
