GE SX Series

ADJUSTABLE FEATURES
SX TRANSISTOR CONTROLS Page 58
Revised May 2003
2. Load the traction motor to 100 amps in 1A and record the
voltage (V
L
) at the control positive and negative power
terminal.
3. Calculate voltage drop (V
Drop
) as follows:
V
Drop
= V
O
- V
L
4. Use the table below to determine the appropriate setting
using the calculated V
Drop
as a reference.
INTERNAL RESISTANCE COMPENSATION
TABLE
Setting V
Drop
Setting V
Drop
2 11.44 17 01.34
3 07.60 18 01.27
4 05.72 19 01.20
5 04.57 20 01.14
6 03.81 21 01.09
7 03.27 22 01.04
8 02.86 23 00.99
9 02.54 24 00.95
10 02.28 25 00.91
11 02.08 26 00.88
12 01.90 27 00.85
13 01.76 28 00.82
14 01.63 29 00.79
15 01.52 30 00.76
16 01.43 31 00.74
FUNCTION 15 BATTERY VOLTS
(Push l5)
This function allows for the adjustment of voltage range for
controls equipped with the Battery Discharge Indication
function. In order for the BDI to operate properly, the
setting as shown in the table must be entered:
Battery volts Set units
36 volts Between 32 and 44
48 volts Between 45 and 69
No BDI Between 251 and 255
FUNCTION 16 STALL MPH
( Push CONT 2 )
This function allows for the adjustment of the traction
motor stall point.
VAL x 0.1 = MPH
Example: Setting of 10 = 10 x 0.1 = 1.0 MPH
FUNCTION 17 CARD TYPE SELECTION
( Push CONT 2 )
This function allows for the selection of the card type used
for your vehicle's application. This function should be set at
a value of 54.
Setting Scale
50 - 54 MPH
55 - 59 KPH
Warning: These settings must be changed by authorized
personnel only, following instructions supplied by the
vehicle manufacturer. Card type selection must be made
within the capabilities of the control panel used and the
supporting electro-mechanical devices. Failure to comply
with proper application standards could result in mis-
operation or damage to the control and/or motors.
FUNCTION 18 LINE CONTACTOR DROP OUT DELAY
( Push CONT 3 )
This function allows for the adjustment of the time delay for
the line contactor drop out.
(VAL x 0.5) + 1.5 = seconds before contactor drop out
Example: Setting of 10 = (10 x 0.5) + 1.5 = 6.5 seconds
FUNCTION 19 MAINTENANCE CODE TENS AND UNITS
HOURS SET
( Push CONT 4 )
This function allows for the adjustment of the tens and
units hours of the maintenance code activation time.
Range 0 to 99
Set 0 to 99
Example 9999
Hours
The following functions have function numbers larger
than the numbers on the Handset keyboard. To access
these functions. Push the CONT key and the number
shown in the following instructions at the same time.
THE SEAT SWITCH MUST BE OPEN.
