GE SX Series User Manual

ADJUSTABLE FEATURES
SX TRANSISTOR CONTROLS Page 61
Revised May 2003
This MIN FIELD takes effect when the Mode 3 settings are
called for by the interactive Dash Display.
FUNCTION 57 MODE 3 FIELD WEAKENING START
( Push CONT 10)
Same as Function 49.
This FIELD WEAKENING START takes effect when the
Mode 3 settings are called for by the interactive Dash
Display.
FUNCTION 58 MODE 3 RATIO
( Push CONT 11 )
Same as Function 50.
This RATIO takes effect when the Mode 3 settings are
called for by the interactive Dash Display.
FUNCTION 59 MODE 3 MPH LIMIT
( Push CONT 12 )
Same as Function 51.
This MPH LIMIT takes effect when the Mode 3 settings are
called for by the interactive Dash Display.
FUNCTION 60 MODE 4 MIN FIELD
( Push CONT 13)
Same as Function 48.
This MIN FIELD takes effect when the Mode 4 settings are
called for by the interactive Dash Display.
FUNCTION 61 MODE 4 FIELD WEAKENING START
( Push CONT 14)
Same as Function 49.
This FIELD WEAKENING START takes effect when the
Mode 4 settings are called for by the interactive Dash
Display.
FUNCTION 62 MODE 4 RATIO
( Push CONT 15 )
Same as Function 50.
This RATIO takes effect when the Mode 4 settings are
called for by the interactive Dash Display.
FUNCTION 63 MODE 4 MPH LIMIT
( Push CONT ESC )
Same as Function 51.
This MPH LIMIT takes effect when the Mode 4 settings are
called for by the interactive Dash Display.
