GE SX Series User Manual

ADJUSTABLE FEATURES
TRANSISTOR PUMP CONTROLS Page 63
Revised May 2003
Section 5.6 Setup Functions for Hydraulic Pump Control
FUNCTION 1: NOT APPLICABLE
This function is not applicable to this type of control and
should not be adjusted.
FUNCTION 2: PERCENT ON-TIME ADJUSTMENT
(Push 2)
This function allows for the adjustment of the percent on-
time of the control.
Range 2 – 15% on-time
Setting 0 - 255
Resolution 0.05% per set unit
Example: Setting of 20 = (20 x 0.05) + 2 = 3%
FUNCTION 3: CONTROLLED ACCELERATION
(Push 3)
This function allows for the adjustment of the rate of time it
takes for the control to accelerate to 96% applied battery
voltage to the motor on hard acceleration.
Range 0.1 to 5.5 seconds
Setting 0 to 255
Resolution 0.021 seconds per set unit
Example: Setting of 20 = 0.52 seconds C/A
FUNCTION 4: CURRENT LIMIT
(Push 4)
This function allows for the adjustment of the current limit
of the control. The rating of the control will determine the
range of adjustment for this function. Please refer to the
OEM operating instructions for the control used in your
vehicle.
Range See OEM control C/L curves
Setting 0 to 255
Example: 0 = min. current, 255 = max. current
FUNCTION 7: NOT APPLICABLE
This function is not applicable to this type of control and
should not be adjusted.
FUNCTION 11: SPEED LIMIT 1 (SL1)
(Push 11)
This function allows for the adjustment of the speed limit
(maximum battery volts to the motor) when the SL1 limit
switch input signal is received by the control card. SL1
limit switch is a normally open switch connected to battery
negative, the switch closing enables speed limit.
Range 0% to 100% battery volts
Setting 0 to 255
Resolution 0.375 volts per set unit
Example: Setting of 50=18.75 volts
FUNCTION 12: SPEED LIMIT 2 (SL2)
(Push 12)
Same as Function 11 except using SL2 limit switch for input.
FUNCTION 13: SPEED LIMIT 3 (SL3)
(Push 13)
Same as Function 11 except using SL3 limit switch for input.
FUNCTION 14: SPEED LIMIT 4 (SL4)
(Push 14)
Same as Function 11 except using SL4 limit switch for input.
FUNCTION 16: NOT APPLICABLE
This function is not applicable to this type of control and
should not be adjusted.
FUNCTION 17: CARD TYPE SELECTION
(Push CONT 2)
This function should be set in accordance with the control
type in use in the vehicle:
Function Without Pump Ctr/PMT
High C/L
BDI Lockout 63 - 71
Note: The following functions have function numbers
larger than the numbers on the Handset keyboard. To
access these functions, push the CONT key and the
number shown in the following instructions at the same
time. THE KEY SWITCH MUST BE OPEN.
