GE TOV

GEK-98834B
5
6SHFLDO0RGHOV
TOV------- 9 -0 1 -
Timing: t=0.19 + 0.75 * ( )
TOV ------- 9 -0 2 -
Timing: t=0.375 + 1.5 * ( )
TOV ------- 9 -0 3 -
Instantaneous = 20 ms
TOV ------- 9 -0 4 -
Number or tripping contacts increased
All of the models include one n.o. trip contact, three form C type relays, one for power
supply alarm, one for pickup and one auxiliary trip.
The operating input voltage is as follows depending on the model:
• 20 to 275 VAC in 1 V steps
• 50 to 305 VAC in 1 V steps
• 3 to 66 VAC in 1 V steps
The relay power supply range can be selected from the following choices:
• 24/48 VDC/VAC ± 20%
• 48/125 VDC/VAC ± 20%
• 110/240 VDC ± 20%
110/220 VAC ± 20%
