11
Cable Tie
Cable Tie
Cable Tie
Laundry Tub
Stand Pipe
WARNING
:Make sure the washer is unplugged.
Run some water from the hot and cold faucets to flush
the water lines and remove particles that might clog up
the water valve screens.
FLUSH WATER LINES
1
Installation Instructions
WASHER CONNECTIONS FOR STATIONARY MODELS
WSLS1100 AND WSLM1100
Connect the inlet hose ends to the HOT and COLD
water faucets tightly by hand, then tighten another
2
⁄3
turn with pliers. Turn the water on and check for leaks.
CONNECT TO WATER LINES
2
CAREFULLY MOVE THE WASHER
TO ITS FINAL LOCATION
3
Form a U shape on the end of the drain hose with the
hose pointed toward the drain. Place the hose in a
laundry tub or stand pipe and secure it with a cable tie
(not included).
NOTE: If the drain hose is placed in a stand pipe
without forming a U shape, a siphoning action could
occur. There must be an air gap around the drain
hose. A snug hose fit can also cause a siphoning action.
CONNECT DRAIN HOSE
4
PLUG THE POWER CORD INTO A
GROUNDED OUTLET
5
Insure proper ground
exists before use
