Auxiliary
Controk
Additional controls are located
behind the room cabinet.
To
remove the room cabinet,
see page 5.
VENT
OPEN
Ventilation Control
1
This knob is set at CLOSE at the
factory. When it is in this position,
the vent door is closed and only
indoor air is filtered, cooled or
heated and circulated by the air
conditioner.
Switching the knob to OPEN opens
the vent door to allow some outside
air to enter the room. However,
cooling or heating effectiveness is
reduced when the control is set at
OPEN, so we suggest you don’t
keep it there long.
If the knob is not set all the way in
the CLOSE position, the vent light
will remain on.
D
o
:LOSE
FAN
CYCLE
~
CONT
– HEATING ECONOMY —
NORMAL
~
MAXIMUM
‘FmoN
UNIT
~IOWER
Unit Power
Switch~
This switch is set at
ON
at
the
factory to
allow
the air conditioner
to operate in the cool, heat or fan
only modes and the Freeze Sentinel
to operate if it is needed.
If this switch is set at
OFF, the air
conditioner will not operate in any
mode and the Freeze Sentinel will
not function.
Caution: The Unit Power Switch
is not a power disconnect.
If all
power must be disconnected from
the unit, remove the line cord plug
from the wall outlet, or remove the
fuses, or turn off the circuit
breakers at the power panel.
Fan Cycle
Switch—
This switch is set at
CONT
at the
factory to provide continuous fan
operation in
cool
or heat modes. If
you want the fan to cycle on and off
with the compressor or resistance
heater, set the switch at
~CLE.
Heating
fionomy
Switch—
For maximum heating economy,
this switch is set at MAXIMUM
at the factory. Until the outside air
temperature drops to
15°F.,
the heat
pump is the primary source of heat.
At
15°F.
and below, full resistance
heat takes over.
Set this switch at NORMAL and
the change from heat pump to
resistance heating occurs when the
outside air temperature drops to
35°F.
4
