GE Zoneline Generation-3 2800 Series User Manual

– 44 –
11. Lift the outdoor fan motor and shroud from the
chassis.
10. Remove the 2 Phillips-head screws that hold the
wire cover in place. Remove the wire cover. Pull
the fan motor wires through the opening.
Screws
Wire Cover
9. Remove the 6 Phillips-head screws from the
left side of the fan shroud.
7. Remove the 2 Phillips-head screws that hold the
fan bracket to the bottom of the chassis.
8. Remove the 4 Phillips-head screws from the
compressor side of the fan shroud.
