Connections F2 F3 F4 F5 F14 F16
SV
DV
Suction line
Discharge line
see technical data, Chapter 8
A
Connection suction side, not lockable
7
/
16
" UNF
1
/
8
"
NPTF
1
/
8
"
NPTF
1
/
8
"
NPTF
1
/
8
"
NPTF
1
/
8
"
NPTF
A1
Connection suction side, lockable
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
B
Connection discharge side, not lockable
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
"
NPTF
1
/
8
"
NPTF
B1
Connection discharge side, lockable
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
B2
Connection discharge side, not lockable - - - -
7
/
16
" UNF
7
/
16
" UNF
C
Connection oil pressure safety switch
OIL
-
1
/
8
"
NPTF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
D
Connection oil pressure safety switch
LP
-
1
/
8
"
NPTF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
D1
Connection oil return from oil separator
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
5
/
8
" UNF
5
/
8
" UNF
E
Connection oil pressure gauge -
1
/
8
"
NPTF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
7
/
16
" UNF
F
Oil drain plug
R
3
/
8
"
M22 x 1,5 M22 x 1,5 M22 x 1,5 M26 x 1,5 M26 x 1,5
H
Oil charge plug
1
/
8
" NPTF
1
/
8
" NPTF
M22 x 1,5 M22 x 1,5 M22 x 1,5 M22 x 1,5
J
Oil sump heater
R
3
/
8
"
1)
M22 x 1,5
1)
M22 x 1,5
M22 x 1,5
M22 x 1,5
M22 x 1,5
K
Sight glass
4 hole M6 4 hole M6 4 hole M6 4 hole M6 4 hole M6
3)
4 hole M6
3)
L
Connection thermal protection thermostat
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
1
/
8
" NPTF
P
Connection
for differential oil pressure sensor
- - - -
M20 x 1,5 M20 x 1,5
ÖV
Oil service valve
- - - -
7
/
16
" UNF
7
/
16
" UNF
1)
Oil sump heating optional
2)
No connection available as standard. Available on request (Connection R
3
/
8
"
)
3)
Second sight glass can be attached, Positioning view Y (optional, available only as original equipment)
10| Dimensions and connections F
