GRASSO SYSTEM CONTROL
638660E_chapter2.doc 01.2004/1
MENU 15 „OPERATION MODES“
Control via digital/analogue signals
0
1
2
3
4
5
6
7
Compressor blocked
manual
manual +/--
manual
auto +/--
auto
auto +/--
External
Ext continuous +/--
External
Ext pulses +/--
External
Local set point
External
Remote set point
Service
Manual + Auto
Remote + HW (cont)
Manual + Manual
Auto + Auto
Remote + HW (pulse)
Remote + HW-Loc.SP
Remote + HW-Rem.SP
8
9
10
11
Network
Net continuous +/--
Network
Net pulse +/--
Network
Local set point
Network
Network set point
Remote + Net (cont)
Remote + Net (pulse)
Remote + Net-Loc. SP
Remote + Net-Net SP
Control via GSC buttons
Control via Network
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
- Stop/Start control
- Capacity control
