OPERATING INSTRUCTIONS

GRASSO SYSTEM CONTROL

FOR TWO STAGE CHILLER/ PACKAGES WITH SCREW

COMPRESSORS

_805011_om_gsc_sp2_gbr_1_.doc 11

1.2.3 Operator terminal

[Chapter 1.2. in user manual]

The operator terminal is the interface between the operator and the control unit.

All switching, operating and control actions are carried out via this operator terminal.

fig. 3: GSC operator terminal

System LED’s

B Function keys

C soft keys

D CPU operating mode setting

E digital keybord

F cursor keys

G System keys

System keys LED‘s
