2.
High Discharge Temperature Warning Offset
This parameter is used to set an offset subtracted from the High Discharge Temperature Shutdown parame-
ter. If the discharge temperature exceeds this calculated value, a High Discharge Temperature Warning will
be annunciated. The warning will only be issued if the compressor is running. The value is measured in the
panel temperature units as selected on the Panel Settings screen.
3.1.19 Oil Cooling
Parameter Units Minimum Maximum Default
Oil Cooling Control Signal Selection – See Description
Motorized Liquid Injection Valve
Temperature Set Point
°C 45.0 °C 80.0 °C 65.0 °C
°F 113.0 °F 176.00 °F 149.0 °F
Minimum Valve Position Percent 2% 100% 10%
Proportional Term Unitless 0 500 250
Integral Term s/R 1.0 s/R 250.0 s/R 40.0 s/R
Mode Selection – See Description
Manual Mode Position Percent 0% 100% 0%
Calibrate Time Before Bleed Seconds 5 s 90 s 30 s
Liquid Injection Begin
°C 0.0 °C 140.0 °C 54.4 °C
°F 32.0°F 284.0 °F 130 °F
Liquid Injection End
°C 0.0 °C 140.0 °C 48.9 °C
°F 32.0°F 284.0 °F 120 °F
Liquid Injection Pulse Period Seconds 4 s 30 s 4 s
1.
Oil Cooling Control Signal
This parameter is used to select which temperature value will be referenced for control of the oil cooling sol-
enoid. The options are:
•
Discharge Temperature
•
Inlet Oil Temperature
