B310-001&BDC © 02-2006
Operating instructions ACO 201
Commissioning
Inserting the pressing jaw/adapter for pressing collar/
EN
MapressMAM jaw adapter
Prerequisites
Pressing device is switched off.
WARNING
Danger of crushing by exposed parts
` Do not operate the pressing tool without pressing jaws
` Keep your fingers away from the area of the roller if
there is no pressing jaw inserted
Pressing is only possible once the locking pin has been
pressed in as far as the stop.
Pull out the locking pin
1
Insert the pressing jaw/adapter for pressing collar/
2
MapressMAM jaw adapter into the pressing device
Press the locking pin in as far as the stop
3
17
