Geberit FORS - Page 4

Geberit
Inlet Valves
2
FORS INLET VALVE
FOR BOTTOM CONNECTION
1/2” Art. No. 222.100.00.1
3/8” Art. No. 222.101.00.1
The Geberit Fors cistern inlet valve can be used world wide thanks to different connection versions and
because of the large pressure range in which the filling valve operates: 10-1000 kPa (0.1 to 10 bar). All parts
exposed to pressure are entirely made from PBT, a chlorine and acid resistant material.
Service and spare parts
Geberit Fors cistern inlet valve is maintenance friendly. In the event of a blockage, the silicone diaphragm and lever part can be easily
removed without tools for cleaning. The spare part is supplied as a kit (diaphragm, insert, cover and lever) in one package. After any
maintenance or replacement of the valve, make sure that the fill and spill level of the cistern is correctly adjusted.
ART. NO. 222.101.00.1
ART. NO. 222.100.00.1
CL
WL
25
92
96
71
CL
WL
G 1/2”
CL
WL
G 3/8”
Min. 235
max. 385
41.5
min.9 / max.15
min. 146
max. 296
Waterline
WL
CL
242.487.00.1 Diaphragm and lever
