1000 / 1001 / 1101

CONFIGURABLE TEMPERATURE CONTROLLERS

SOFTWARE VERSION 13.x

code 80343I / Edition 21 - 07-2011

INSTALLATION AND

OPERATION MANUAL

96

108

96

115

92

92

100

10

115

48

108 96

70

115

92

44,5

100

10

For correct and safe installation observe the warnings

contained in this manual

1 • INSTALLATION

• Dimensions and cut-out;

panel mounting

Panel mounting:

To fasten the instruments insert the block into the seats on the sides

of the box. To mount two or more instruments side by side respect the

dimensions swown above.

2 •

TECHNICAL SPECIFICATIONS

!

Display

Keys

Accuracy

Main input

(adjustable digital filter)

TC type(Thermocouples)

Cold junction error

RTD type

(scale configurable within

indi-cated range, with or

without decimal point)

Max. RTD line

resistanceRTD

Safety

°C / °F selection

DC - Linears

Control actions

pb - dt - it

2x3 digit green LEDs,

digit height 14-10-20mm

3 mechanical keys (Raise, Lower, F)

0.5% f.s. ±1 digit at 25° ambient

temperature

TC, RTD,

Sampling time 120 msec

for 1000

J (Fe-CuNi) 0...800°C / 32...999°F

K (NiCr-Ni) 0...999°C / 32...999°F

N (NiCr-Si-NiSi) 0...999°C / 32...999°F

S (Pt10Rh-Pt) 0...999°C / 32...999°F

R (Pt13Rh-Pt) 0...999°C / 32...999°F

T (Cu-CuNi)

-100...400°C / -148...752°F

for 1001, 1101

J (Fe-CuNi) 0...800°C / 32...999°F

K (NiCr-Ni) 0...1300°C / 32...1999°F

N (NiCr-Si-NiSi)

0...1300°C / 32...1999°F

S (Pt10Rh-Pt) 0...1600°C / 32...1999°F

R (Pt13Rh-Pt) 0...1600°C / 32...1999°F

T (Cu-CuNi)

-100...400°C / -148...752°F

Selection with faceplate keys.

0.05°C for each 1°C of variation

RTD 2/3 wires

for 1000

Pt100 -19.9...99.9°C / -19.9...99.9°F

Pt100 -199...400°C / -199...752°F

RTD 2/3 wires

for 1001, 1101

Pt100

-199.9...199.9°C / -199.9...199.9°F

Pt100

-200...400°C / -328...752°F

detection of short circuit or opening of

probes, LBA alarm, HB alarm

Faceplate configurable

0...50mV, 10...50mV

Input impedance > 1MΩ

For signals 0...10V, 0...20mA, 4...20mA

use only with dividers / shunt outside the

instrument.

Pid, Autotune, on-off

• Proportional band: 0.0...99.9% f.s.

• Integral time:

0.0...99.9 min

• Derivative time:

0.0...9.99 min (0.0...19.99 min)

• Reset power (positioning of proportional

band): 0...100%.

• Hysteresis (only for On/Off control):

-199...999 (-999...1999) digits.

Other specifications at page 2
