gefran 1250 Series - Advanced Configuration Tools; GF_eXpress Configuration; Zapper Portable Configurator

SERIES 650 / 1250 / 1350
GO!
GO!
1. Copy
The parameters are copied from the PC on which the
GF_eXpress configuration tool is installed directly to the
controller, even if powered off.
2. Paste
With the mini USB cable, you can import the configuration to
one or more controllers, even if powered off.
3. GO!
CONFIGURATION WITH GF_eXpress
CONFIGURATION WITH Zapper
2. Paste
The Zapper connects to the controller via the microUSB
connector cable to paste the configuration.
3. GO!
Click to copy the configuration to one or more controllers.
The 650 – 1250 - 1350 controllers can be configured from the PC and from the Zapper, a portable, battery-powered configurator with microUSB
connection cable used for easy and safe copying/pasting of complete configurations.
- Copied from other controllers
- Copied from GF_eXpress
Configuration can be done with the controller powered and also not powered i.e., on controllers just removed from the package or already instal-
led on the machine.
This function is extremely useful for OEMs and End Users who need to program multiple controllers on more than one machine.
1. Copy
The parameters are copied from the PC on which the
GF_eXpress configuration tool is installed or from another
controller and pasted to the Zapper.
CONFIGURATION WITH GF_eXpress AND WITH Zapper
USB
CLICK
USB
USB
USB
