gefran 2400 User Manual

14
80290C_MHW_2400_0908_ENG
7
8
9
10
11
+
S
+
S
+
+
IN3, IN4 linear inputs with 3-wire transmitter powered by instrument
IN4
+ 24VTransmitter
power supply
IN3
7
8
9
10
11
+
+
+
+
IN3, IN4 linear inputs with 2-wire transmitter powered by instrument
IN4
Transmitter power supply
IN3
IN3, IN4 linear inputs (I)
7
8
9
10
11
+
+
IN3
IN4
IN3, IN4 linear inputs (V)
7
8
9
10
11
+
+
IN3
IN4
7
8
9
10
11
+
+
+
IN3, IN4 potentiometer inputs
IN4
IN3
Vpot is the potentiometer power supply voltage.
The 10Vdc probe power supply can be used if available.
Vpot 10Vdc
(terminal 5)
+ 24V
Electrical Connections (for all models)
