gefran 2400 User Manual

46
80290C_MHW_2400_0908_ENG
Display Default CONF Description
SdE.6 0 Character E alarm string 6
Ar.7 0 Alarm reference 7
At.7 0 Type alarm 7
xy.7 -1 Alarm hysteresis 7
rA.7 0 Activation time alarm 7
bt.7 0 Time base for activation time alarm 7
Sda.7 0 Character A alarm string 7
SdB.7 0 Character B alarm string 7
Sd(.7 0 Character C alarm string 7
SdD.7 0 Character D alarm string 7
SdE.7 0 Character E alarm string 7
Ar.8 0 Alarm reference 8
At.8 0 Type alarm 8
xy.8 -1 Alarm hysteresis 8
rA.8 0 Activation time alarm 8
bt.8 0 Time base for activation time alarm 8
Sda.8 0 Character A alarm string 8
SdB.8 0 Character B alarm string 8
Sd(.8 0 Character C alarm string 8
SdD.8 0 Character D alarm string 8
SdE.8 0 Character E alarm string 8
Ar.9 0 Alarm reference 9
At.9 0 Type alarm 9
xy.9 -1 Alarm hysteresis 9
rA.9 0 Activation time alarm 9
bt.9 0 Time base for activation time alarm 9
Sda.9 0 Character A alarm string 9
SdB.9 0 Character B alarm string 9
Sd(.9 0 Character C alarm string 9
SdD.9 0 Character D alarm string 9
SdE.9 0 Character E alarm string 9
Ar.10 0 Alarm reference 10
At.10 0 Type alarm 10
xy.10 -1 Alarm hysteresis 10
rA.10 0 Activation time alarm 10
bt.10 0 Time base for activation time alarm 10
Sda.10 0 Character A alarm string 10
SdB.10 0 Character B alarm string 10
Sd(.10 0 Character C alarm string 10
SdD.10 0 Character D alarm string 10
SdE.10 0 Character E alarm string 10
Lo.AL 0 Lower limit alarm setpoint
xi.AL 3500 Upper limit alarm setpoint
rEL 0 Alarm state in Fault Action condition
Menu
00vvtt
rL.1 1 Output reference OUT1
rL.2 2 Output reference OUT2
rL.3 3 Output reference OUT3
rL.4 18 Output reference OUT4
typ.An 0 Type of retransmission output W
riF.An 0 Output reference W
Lo.An 0 Minimum scale output W
xi.An 3500 Maximum scale output W
ALS 2 Select probe power supply
Menu
PPAASS
PAS 0 Pass-word
Pro 0 Protection code
Menu
xxrrdd
hd.1 8 Enable multiset/type process/line freq.
Fvnc.A 0 Math function A
In1.A 0 First operand of Fvnc.A
In2.A 0 Second operand of Fvnc.A
0pEr.A 0 Operator of Fvnc.A
(1.A 0 Coefficient (1.A
(2.A 0 Coefficient (2.A
(3.A 0 Coefficient (3.A
