Gehl HL 360 User Manual

A
WARNING: To prevent unexpected or
HOURMETER (Fig. 5)
unathorized engine starting, especially
while performing service,
BE SURE to
For added convenience in proper routine maintenance
performance, an
Hourmeter is provided to automati-
remove the
Key BEFORE leaving the Operator's
Compartment. .
cally record engine running time. Refer to the
Maintenance Schedule in the back
of this manual for
THROTTLE (Fig. 5)
Engine RPM is varied with a hand-operated Throttle. As
displayed
by the Decal, pushing the Throttle down
(toward the
Rabbit Symbol) increases RPM and pulling
the Throttle up (toward the Turtle Symbol) decreases
RPM.
Fig. 5
CHOKE (Fig. 5)
A hand-operated mechanical Choke is furnished for cold
engine starting assistance. Pull the Choke
out to start the
engine
and push it in all the way after the engine has
reached running temperature.
prescribed times and service routines
to be performed.
HYDROSTATIC PUMP DRIVE B EL T ID LER (Fig. 5)
A Handle is provided to engage/disenga ge the Hydro-
static
Pump Drive Belt Idler.
A
WARNING: BE SU RE to disengage the Idler
Handle BEFORE starting the engine, after
shutting the engine off and whenever the
Lift
Cylinder Lock is being enga ge d or di sengaged.
HYDRAULIC/HYDROSTATIC OIL LEVEL
INDICATOR (Fig. 6)
The Oil Level for the Loader Hydraulics system, serving
both the Hydrostatic Drives and Lift and Tilt Cylinders,
is visually displayed by a Level Indicator Tube on the
right side behind the Seat Backrest. A Decal
is placed
next
to the Indicator to mark the proper operating oil
level.
Fig. 6
OPERATION
A
WARNING: BEFORE starting the
Loader engine and attempting to
operate the Skid Steer Loader for the
first time, review the
WARNINGS section and
the Controls & Safety Equipment section of this
manual.
Know how to STOP the Loader
BEFORE starting it.
STOPPING THE LOADER
1. Move the Traction T -bar to the "N eutral" position.
2. LOWER THE LOAD ARMS to rest onto the
Loader Frame.
3. Place the Lift/Tilt T-bar in "Neutral" and rest the
Bucket
or Fork onto the ground.
12
