\: ~ " 1, ', " S \
,
,
\ \, ... - ."" '- ""~ \
, .
\. ... .. ... _---- _. __ .. _-_.. __ .' I.. L _ ' ~ " _'''' ••••
Fig.11
Dumping the Bucket or Fork
Onto a Pile
Carry the loaded Bucket or Fork low until reaching the
pile. Then, stop forward motion and raise
the Load Arms
high enough so
that the Bucket or Fork clears the top of
the pile. Then , slowly move the Loader ahead to position
the Bucket
or Fork to spill the material on top ofthe pile.
Empty the Bucket
or Fork and back the Loader away
while lowering the Load Arms
and rolling the Bucket or
Fork back.
Into a Box
Carry the loaded Bucket or Fork low and approach the
truck, trailer or spreader box squarely with the sideofthe
box. Then , stop forward motion well away from the side
of the box to raise the Load Arms and clear the side of the
box. Slowly move the
Loader ahead to position the
Bucket or Fork over the inside of the box. After the
material
is dumped, back away from the box and lower
the
Load Arms while rolling the Bucket or Fork back.
,
,
I ,
I ,
i
I
~ :
I
i ~ :
: ,~,:
S :'~: . :~;~\ .. ,~" ~ . ~
~ ~ , \ : : ~: 'L~ : '~~ ' ',' ~
~ ~ . :~ '~' ~ ',: ,:. : ' ~, ' ~: ~
I
I
:
: ~":
~J~:
I
I
I \"- .. "".- .. ".', . ~
I '
~ -' '- 1, ' ," S
\ ' : ~-'-' ~ ':
\. - -- - _. _- --------- -- -_ ... _- - -)
I.. c,:;· .x· ... ....
Fig. 12
NOTE: A Bucket can be conveniently used to
•
spread the pile inside the box
by positioning
the Bucket Cutting Edge against the near side of the
pile and rolling the Bucket back while slowly driving
forward and pushing the top of the pile forward.
Over a Solid Embankment
A
WARNING: DO NOT drive too close to an
excavation or ditch!
BE SURE surrounding
ground has adequate strength
to support
weight of the Loader and load!
Carry the loaded Bucket or Fork low while traveling
toward
the dumping area. Stop the Loader at the position
where
the Bucket or Fork extends half-way over the edge
of the embankment. Then , roll the Bucket or Fork
forward and raise the Load Arms to dump the material.
After
the material is dumped, back away from the
emb ankment while lowedn g tbe Load Arms and rolling
the Bucket
or Fork back
16
