High Flow Auxiliary Hydraulic Controls
In addition to standard flow auxiliary hydraulic
connections, some loaders are shipped with
reversible high flow auxiliary hydraulics. Coupler
hookup is located on the right lift arm. High flow
auxiliary hydraulics are used for operating high oil
flow hydraulic attachments (cold planer,
snowblower, etc.)
A 3-position control lever is located behind the
right control handle. The lever is spring centered
with a detent in the forward position for continuous
operation.
908274/BP1202 32
Fig. 20: High Flow
Control
